Definitive Technology DYMENSION DM90 Integrated Height Module for Dymension DM80 and DM70 Speakers (Pair)
Definitive Technology DYMENSION DM90 Integrated Height Module for Dymension DM80 and DM70 Speakers (Pair) - Definitive Technology
The Dymension⢠DM90 integrated height module attaches to Dymension DM80 and DM70 bipolar tower speakers to provide upward-firing drivers that make the towers Dolby Atmos-enabled. With DM90s attached to DM80 or DM70 speakers, you can create the Dolby Atmos-enabled and DTS:X speaker system of your dreams.
KEY BENEFITS
Purpose-Built Add-On Modules
An upward-firing mid/bass woofer and tweeter project sound toward the ceiling where it reflects back to you, providing a sense of height that translates to a more immersive listening experience.
Plug-and-Play Integration
DM90 connects easily to Dymension⢠DM80 or DM70 bipolar tower speakers. The speakers and the height module feature a snap-in connection system that makes electrical connections and secures the height module to the top of the speaker.
BDSS System and Linear Response Waveguide
DM90âs 5.25â mid/bass woofer features our patented Balanced Double Surround System⢠technology. BDSS improves midrange driver excursion and provides a wide, uniform soundstage with seamless mid/bass integration. A Linear Response Waveguide⢠extends and smooths off-axis dispersion for great sound everywhere in the room.
Aluminum Oxide Tweeters
DM90âs rigid, well-damped tweeter utilizes a new aluminum oxide design that provides smooth extended response with crisp transients and exceptional definition, for lifelike realism whether youâre immersed in a movie or your favorite tunes.
Timbre-Matched
Consistent sound across Definitive Technology series gives you the flexibility to mix and match Dymensionâ˘, Dymension CI, and Mythos speakers to design your dream home theater and whole-home system.
PRODUCT FEATURES:
- Purpose-built add-on height modules for Dolby Atmos and DTS:X
- Upward firing drivers bring Atmos soundtracks to life
- Easy, quick, and secure plug-and-play installation
- Aluminum oxide tweeter produces crisp, sparkling highs
- 5.25â BDSS⢠driver provides balanced sound, wide listening area
- Timbre-matched with other Definitive Technology speakers
- Accommodates Dymension⢠DM80 and DM70 bipolar tower speakers
- Understated design so the speakers virtually disappear into the room
SPECIFICATIONS:
- Dimensions (H Ă W Ă D): 6.0 Ă 7.3 Ă 15.3 in, 152 Ă 185 Ă 389 mm
- Weight: 10.1 lbs (4.6 kg)
- Color: Black
- Grille Material: Acoustically transparent black cloth (not removable)
- Tweeter: (1) 1 in. aluminum oxide dome
- Midrange/Midbass: (1) 5.25 in. BDSS⢠with Linear Response Waveguideâ˘
- Frequency Response: 81 Hzâ30 kHz (-10dB), 130 Hzâ27 kHz (-3dB)
- Nominal Impedance: 4Ί (8Ί compatible)
- Sensitivity: 90dB (2.83V/1m)
- Recommended Amplifier Power Rating: 25â100W
- Certifications: Dolby Atmos
