Klipsch PSM-800-SW-T 8" Indoor/Outdoor Professional Surface Mount Subwoofer (Each) - Klipsch

MORE BASS, LESS SPACE WITH THE ALL-NEW TRACTRIX® HYPERFOLD PORT™
Klipsch is all about high efficiency, low distortion. Building upon that legacy, we’re introducing the all-new patented Tractrix® Hyperfold Port™ engineered to extend port length for maximum bass power via proprietary five-step folded design. Its increased airflow eliminates chuffing and port noise while providing a greater dispersion pattern for larger coverage areas.

IPX6 RATED FOR COMMERCIAL ENVIRONMENTS
Perfect for indoor and outdoor commercial installations around the globe, the Klipsch PSM-800-SW-T is IPX6 Rated. Your clients will rest easy knowing their new speakers will be water-resistant and rainproof for the most challenging commercial environments.

MULTIPLE TAP SETTINGS
There is also a bypass position that allows normal 8 ohm operation for installations that do not require a transformer

SET SCREWS ON GRILLE
The included set screws on each grille ensures a secure fit between the speaker and grille, while making sure the grilles stay on the enclosures regardless of the environment.

ENGINEERED FOR MUSIC REINFORCEMENT APPLICATIONS
These unobtrusive, easy-to-install loudspeakers feature a transformer-less design for 70V/100V distributed-line systems with two wattage settings. Since transformers severely limit a subwoofer’s capabilities, this unique design is the perfect solution when building a great sounding commercial system

PHOENIX CONNECTOR FOR SIMPLIFIED INSTALLATION
The PSM-800-SW-T employ a phoenix connector for quick and intuitive connection.

What to expect in the box:

• PSM-800-SW-T 8" Indoor/Outdoor Professional Surface Mount Subwoofer (Each)

Product Details:

• FREQUENCY RESPONSE(*1): 38Hz-200kHz +/- 4dB, 30Hz -10dB
• POWER HANDLING(*2): 150 watts (25.4V) 40Hz-200Hz (600 watts peak)
• CALC. MAX. CONT. OUTPUT(*3): 107dB
• SENSITIVITY(*4): 88dB
• NOMINAL IMPEDANCE: 8 ohms 4.2 ohms at 36Hz minimum
• TRANSDUCERS: 8" woofer Part #1072158
• ENCLOSURE MATERIAL: All Weather ABS Plastic, Paintable
• ENCLOSURE TUNING: Vented via 3 folded TRACTRIX ports
• INPUT CONNECTORS: 4 pin euro block
• TRANSFORMER TAPS: " 70V: 70W, 35W, 100V: 70W, 35W
• Bypass position: 8 ohms nominal
• OVERALL WIDTH: 15.5"
• OVERALL HEIGHT: 12"
• OVERALL DEPTH: 9.31"
• OVERALL DEPTH W / BRACKET: 11.12"
• WEIGHT: 15.75 lbs (7.15kg)
• Black Version UPC: 743878092509
• Black Version MPN: 1080129
• White Version UPC: 743878092516
• White Version MPN: 1080130
• Notes
• (*1): 1m, half space, anechoic
• (*2): AES standard, continuous pink noise, 6dB peaks
• (*3): Calculated at 1m at power handling power input
• (*4): SPL at 1m half space, anechoic with 2.83V pink noise input
