Rockustics SubScape 12 Outdoor 12" In-Ground Band-Pass Subwoofer - Rockustics

The Subscape 12 is a direct-burial, 12" subwoofer to complement Periscape speakers. With 300 watts (RMS) of power handling, it brings ground-shaking bass response to your outdoor installations and is the perfect companion to Periscape spike-mount speakers. Once installed, the only visible part of the speaker is a discreet, brown vent cap. One Subscape subwoofer is suitable for installations of up to 7 Periscape units; additional subwoofers are recommended for larger installations. The Subscape 12 may also be used with other Rockustics speakers or other outdoor products. A built-in transformer provides convenience for 70V installations; the subwoofer may also be operated in 8 ohm direct mode. When installed in 8 ohm mode, we recommend the use of the PhaseTech P350 subwoofer amp.

What to expect in the box:

• SubScape 12
• Wire
• Nuts

Product Details:

• System Type: 12” In-Ground Bandpass Subwoofer (300 W transformer for 70.7 V or transformer bypass applications)
• Impedance (Nominal): 8 ohm
• Sensitivity dB @ 2.83 V / 1 M: 87 dB
• Sensitivity dB @ 1 W / 1 M: 87 dB
• Frequency Response ( ±3 dB): 27 Hz - 110 Hz
• Frequency Response ( ±10 dB): 25 Hz - 150 Hz
• Max. Program Power: 600 W
• Max. Continuous Power RMS: 300 W
• Max. SPL dB @ 1 M: 111.5 dB
• Tap Selector: Wire leads
• Transducer: Low-Frequency Driver: 12” Polypropylene Cone w/ Butyl Rubber Surround
• Low-Frequency Voice Coil: 2.0 in / 50.8 mm
• Crossover Frequency: 90 Hz
• Network Type: Low Pass: 12 dB per octave, 2nd order
• Network Type: High Pass: N/A
• Enclosure Material: Rotomolded ABS plastic
• Grille: Brown vent cap
• Inputs: Wire leads
• Colors: Brown
• Length: 29 in / 736.6 mm
• Width: 14 in / 355.6 mm
• Height: 25 in / 635 mm
• Weight: 37.75 lbs / 17.12 kg
• Packaging: One per box
• Certifications: CE, RoHS
• UPC: 748252173386
• MPN: SUBSCAPE 12
