MoFi StudioDAC Digital-to-Analog Converter - MoFi

Designed in collaboration with Mytek Audio engineer Michal Jurewicz, made in the USA, and voiced by MoFi Electronics. The StudioDAC supports DSD, DXD, and full MQA decoding + rendering. StudioDAC leans on a low-noise clock generator and Apodizing Filter to recreate music with remarkable openess and purity. Partner with a streamer or computer via USB 2.0, S/PDIF, or Toslink and see the signals incoming format and resolution with the LED indicators to confirm bit-perfect playback.

The Essence of High-Fidelity Audio
The StudioDAC is the embodiment of meticulous craftsmanship and uncompromised audio quality. With its multiple input options including USB 2.0, S/PDIF, and Toslink, the StudioDAC seamlessly integrates with various audio sources. The full MQA decoding and rendering capability ensures an authentic listening experience, especially for MQA-encoded tracks.

Advanced Technology for Pure Sound
At the heart of the StudioDAC is a low-noise precision clock generator, minimizing jitter to deliver an unadulterated audio experience. The inclusion of an Apodizing Filter eradicates sharp-edged high frequencies and pre-ringing artifacts, producing a natural sound that closely mirrors the original analog signal. LED indicators provide intuitive feedback on the audio format and resolution, ensuring bit-perfect playback. Additionally, an outboard power supply is included, enhancing low-noise playback and offering opportunities for future upgrades.

What to expect in the box:

• StudioDAC Digital-to-Analog Converter

Product Details:

• Features
• DSD, DXD, and 32-bit/384 PCM playback
• Custom Designed and Manufactured in the USA
• USB2.0, S/PDIF, and Toslink, inputs
• MQA Decoder
• Outboard power supply
• Specifications
• Digital Inputs: 1x Coax (S/PDIF), 1x Optical (TOSlink), USB B
• D/A Converter: ESS9038Q2M
• Sampling Rates: 32/44.1/48/88.2/96/176.2/192/352.8/384 kHz
• DSD Support (USB): DSD64, DSD128
• MQA Support: Full MQA decode + render by hardware
• Bit Depth (USB): 16-32 bits
• Bit Depth (COAX, Toslink): 16-24 bits
• Frequency Response: 20Hz - 20kHz +/- 0.2db
• Analog Out: 1x Fixed Level Out (RCA)
• Output Voltage: 2.5 VRMS @ 0dbfs
• THD+N: <0.002% 20-20Khz
• Dynamic Range: 115dB (A-weighted)
• SNR: >114dB (A-weighted)
• Crosstalk @ 10KHZ: -110dB
• Output Impedance: 75 Ohms (unbalanced)
• Linearity: <+/-0.25db @ -110db
• Power Supply (external 100-240VAC): +12 Vdc 3.3 Amp center positive
• Output Connector (external 100-240VAC): 5.5/2.5mm barrel connector
